PALLET HANDLER

Single Double Pallet Handler

Single double pallet handler can handle one or two pallet with goods quickly on one time.

Technical Specifications

Model	Capacity@Load Center (kg@mm)	Mounting Class	Outer Fork Range (mm)	Inner Fork Range (mm)	Frame Width A (mm)	Forks	Backrest Size (mm)	VCG (mm)	HCG (mm)	ET (mm)	Weight (kg)
SLS-A201	1600@500	2	662-2038	330-815	1100	1000*80*50	1375	260	217	232	545
SLS-A202	1600@500	2	670-2045	340-855	1100	1150*80*50	1200	257	242	232	580
SLS-A203	1600@500	2	560-1960	230-390	1200	1150*80*50	1200	278	235	232	522
SLS-A204	1600@500	2	870-2300	540-720	1400	1100*80*50	1375	258	218	232	615
SLS-A205	1600@500	2	745-2430	415-720	1500	1100*80*45	1380	266	212	232	596
SLS-A206	1600@500	2	750-2430	420-850	1400	1100*80*45	1370	258	215	232	622
SLS-A207	1600@500	2	616-1530	286-470	1100	1170*80*50	1370	255	244	232	560
SLS-B201	2500@600	3	648-2022	318-827	1092	1200*80*45	1370	268	250	228	538
SLS-B202	2500@600	3	670-2045	340-855	1100	1150*80*50	1200	300	242	232	618
SLS-B203	2500@600	3	560-1960	230-390	1200	1150*80*50	1200	278	330	235	525
SLS-B204	2500@600	3	660-2035	330-815	1100	1000*80*50	1500	322	209	232	595
SLS-B205	2500@600	3	590-1600	230-590	1200	2000*80*50	1500	265	387	228	680
SLS-B206	3000@600	3	710-2100	380-700	1200	1070*80*50	1500	345	219	251	743
SLS-B207	2500@600	3	660-2160	330-520	1100	1070*80*50	1700	369	209	230	600
SLS-B208	2500@600	3	740-2060	410-530	1200	1070*80*50	1200	408	216	232	670
SLS-B209	3200@600	3	740-2060	410-530	1200	1070*80*50	1900	405	216	248	738
